Ultra-Low Refrigerated Circulator FPW91-SL
water-cooled
Working temperature range °C -91 ... 100
Temperature stability °C ±0,2
Cooling capacity
Medium ethanol °C
kW +20 0 -20 -40 -60 -80 -90
5.0 5.2 4.7 4.0 3.5 2.3 0.8 0.2
Cooling compressor 2-stage
Refrigerant R404A / R508B
Cooling water flow rate at 20 °C l/h ca. 400
Overall dimensions (WxDxH) cm 85x76x116
Filling port dia. cm 7
Special unit with bath opening (WxL) cm 28x23
Bath depth cm 20
Filling volume liters 22
Weight kg 303
Ambient temperature °C 5 ... 40
Cooling water connection G3/4“ male thread
Mains power connection
400 V/3P/50 Hz
V/ Hz 360-440V/3PNPE/50Hz
Current draw (at 400 V) A 32
Mains power connection
208 V/3P/60 Hz
V/ Hz 207-253V/3PPE/60Hz
Current draw (at 230 V) A 32
Current draw: Refer to notice page 16
All measurements have been carried out at: rated voltage and frequency ambient temperature: 20 °C
Technical changes without prior notification reserved.
