21
Example: FL300

15 A M P
15 A M P
 Connect the tubings for cooling the external system to
the pump connectors M16x1 for feed and return (12) on
the rear of the recirculating cooler.
- Feed – Return
 Connect a piece of tubing to the overflow connector (13)
and drain into a suitable vessel, which always has to be
placed lower thant the exit „Overflow“.
 Do not set up the unit in the immediate vicinity of heat
sources and do not expose to sun light.
 Before operating the unit after transport, wait about one
hour after setting it up. This will allow any oil that has
accumulated laterally during transport to flow back down
thus ensuring maximum cooling performance of the
compressor.
Caution:
Securely attach all tubing to prevent slipping.
