45. DEFAULTS
Set various system configuration settings to the factory default.
Press EXECUTE to enter the menu.
Press MENU ( ) to scroll through and select which item(s) to default.
ØPATCH1?
Sets the dimmer phase patch to AABBCC. This is the default setting.
ØPATCH2?
Sets the dimmer phase patch to AAAAAA.
CURVES?
Sets all 120 dimmer curve profiles to Square Law curve.
ANA-OFF?
Clears the control channel patch for all 4 analog inputs.
V-LIMIT?
Sets the output voltage limit to full (127.5) on all 120 dimmer outputs.
DCPATCH?
Clears the dimmer to channel patch and configures it for 1:1 operation.
FD-TIME?
Sets the fade time at 5 seconds for all 12 scenes.
2 ROOM?
Sets the two room assignment to room “A” on all 120 dimmer outputs.
SURE???
Press EXECUTE to select the item to default. Are you sure?
DONE!!!
Press EXECUTE to set the selected default.
Press ESCAPE or RESET to exit the menu.
46. LCD VIEW
Adjust the contrast of the LCD Display for optimum viewing.
Press EXECUTE to enter the menu.
ADJUST
Press MENU ( ) to adjust the contrast.
Press ESCAPE to exit the menu and save the desired LCD view.
Press RESET to exit the menu without saving.
The menu will automatically timeout after 5 minutes of inactivity and save.
