2. FADETIME
Set the fade time for each of the 12 scenes from 0 to 99 seconds.
The factory default is 5 seconds for all 12 presets.
Press EXECUTE to enter the menu.
S>01T 05
Displays the scene (S>01) and assigned fade time (T 05).
S>12T 05
Press MENU (
) to select a different scene from 01 to 12.
S 12T>05
Press EXECUTE to toggle between scene (S>) and fade time (T>) selection.
S 12T>99
Press MENU (
) to select a different fade time from 00 to 99 seconds.
Press ESCAPE to exit the menu and save the selected fade time.
Press RESET to exit the menu without saving.
The menu will automatically timeout after 5 minutes of inactivity and save.
3. SNAPSHOT
Record DMX levels into the backup scenes.
Provides a quick and easy way to save control channel levels into each of the 01 to
12 backup scenes using a DMX source.
Press EXECUTE to enter the menu and activate snapshot mode.
SAVE >01
Displays the scene to save from 01 to 12.
SAVE >12
Press MENU (
) to select a scene from 01 to 12.
SAVE >12
Press EXECUTE to save the DMX levels in the selected scene.
SURE ???
Press EXECUTE if you are sure the DMX levels are set as intended.
DONE !!!
DMX levels have now been saved in the selected scene.
NO RX!
DMX is not being received on either input, so a snapshot is not possible.
Press ESCAPE to back-up within the menu, or exit/deactivate snapshot mode.
Press RESET to exit/deactivate snapshot mode.e menu, or exit/deactivate snapshot mode.
Press RESET to exit/deactivate snapshot mode.
4. DIM TEST
Test the dimmer outputs one at a time, or all at once.
A technician’s best friend! Used for troubleshooting the dimmer outputs and field
wiring to the load.
Press EXECUTE to enter the menu and activate dimmer test mode.
D001 L00
Displays the active dimmer (D) and the test level (L).
D120 L00
Press MENU (
) to select the dimmer (D) to test from 001 to 120.
DALL L00
Press MENU (
) to select and test all (ALL) the dimmers at once.
D001
L00
Press EXECUTE to toggle between dimmer (D) and level (L) selection.
D001
L00
The cursor (_) position indicates dimmer (D) or level (L) selection.
D001
LFL
Press MENU (
) to select the desired test level from 00% to 100% (FL).
D001
LFL
Press ESCAPE to toggle the test level between full-on (FL) and off (00).
D001 LFL
Press EXECUTE to toggle the cursor (_) and select another dimmer to test.
Press ESCAPE or RESET to exit the menu.
The menu will automatically timeout after 5 minutes of inactivity.
5. MONITOR
View the control level to each dimmer output.
The dimmer control level is displayed as a 9-bit value from 000 to 512. This menu
does not timeout automatically and will continue to monitor indefinitely.
Press EXECUTE to enter the menu and activate monitor mode.
D001L000
Press MENU (
) to select the dimmer (D) output to monitor from 001 to 120.
D120L512
Display shows dimmer 120 has full-on (512) control.
Press ESCAPE or RESET to exit the menu.
NOTE: The control level value will not reach 512 when voltage output limiting is
activated, or when regulation is enabled and the line voltage is greater than
118 VAC.
