Detailed Programming
of System Configuration Menu Items
NOTE: The programming switches can be locked out to prevent inadvertent configuration
changes. To toggle between “LOCKED!!” and “UNLOCKED” press and hold down the EXECUTE
and then ESCAPE switches at the same time for 4-5 seconds.
The sequence of the following system configuration menu items appear as the MENU DOWN
( ) switch is pressed. Pressing the MENU UP ( ) switch will sequence the system
configuration menu items in the opposite order. Pressing and holding either of the MENU UP/
DOWN ( ) switches will speed up the scroll rate, which can be helpful to speed up the
configuration time.
1. SCENESET Enable and setup 12 different backup scenes.
When scene mode is activated the selected scene will be held with no timeout until
the menu is exited. The 120 control channel levels are configured within the menu
and can be modified on the fly. Scene mode is useful when an external controller is
not available and independent internal control is required.
Press EXECUTE to enter the menu and activate scene mode.
SCENE>01 Displays the scene (01) to be activated.
SCENE>12 Press MENU ( ) to select a different scene from 01 to12.
CTRL: ON Control (CTRL) is ON via the selected scene.
CTRL:DMX Control (CTRL) is via DMX and takes priority over scene mode.
CTRL:HLD Control (CTRL) is via DMX status hold (HLD) and takes priority over scene mode.
SCENE>12 Press EXECUTE to activate the selected scene.
SCENE:12 The colon (:) flashes twice per second while fading to the selected scene.
SCENE:12 The colon (:) stops flashing when fade is complete and the selected scene is active.
SCENE>12 Press MENU ( ) to select a different scene from 01 to 12.
SCENE 12 Press EXECUTE to modify the selected scene.
C001 L00 The second line on the LCD indicates the control channel (C) and level (L).
C120 L00 Press MENU ( ) to select the control channel (C) to modify from 01 to 120.
C120 L00 Press EXECUTE to toggle from channel (C) to level (L) selection.
C120 L00 Press ESCAPE to toggle from level (L) to channel (C) selection.
C120 L00 The cursor (_) position indicates channel (C) or level (L) selection.
C120 LFL Press MENU ( ) to select the level (L) for the channel from 00% to 100% (FL).
CLEAR??? Press EXECUTE to clear the selected preset, and set all channels to 00 level.
SURE ??? Press EXECUTE if you are sure to clear the selected preset.
DONE !!! Indicates the selected preset has been cleared.
WAIT... Press ESCAPE to exit and the menu and save programmed scene levels.
Press ESCAPE to back-up within the menu, or exit/deactivate scene mode.
Press RESET to exit scene mode without saving programmed scene levels.
NOTE: When scene mode is activated: DMX and DMX status hold (SH TIME)
automatically takes precedence over scene mode. The analog input levels
are merged (HTP) with the scene levels. If the analog inputs are configured
for load shed mode the inputs will take precedence over the active scene.
The security alarm (S-ALARM) input is merged (HTP) with the scene levels
while the fire alarm (F-ALARM) input automatically takes precedence.
Scene mode (SCENEMOD) and the auxiliary input (AUX IN) are temporarily
enabled. Scene mode will only activate dimmers assigned to room “A”.
