DIGI-HD60C Installation Guide
Technical Specifications
I/O Connections
HDMI
One (1) HDMI Type A Receptacle
Twisted Pair
One (1) 8P8C port (Shielded RJ45)
IR Input
One (1) 3.5mm TRS Jack
IR Output
One (1) 3.5mm TS Jack
RS232
One (1) 3-Pole Euroblock connector
24V DC Power
One (1) 5.5 mm Outside Diameter, 2.1 mm Inside Diameter Barrel (Locking)
Supported Audio, Video and Control
Maximum Video Compatibility at 60 m
Deep Color 36/30/24 Bit at 1080p
Maximum Video Compatibility at 35 m
Deep Color 48 Bit at 1080p, 3D, and 4k x 2k
Supported 3D Formats
Field Alternative (interlaced), Frame Packing, Line Alternative Full, Side-By-Side Half, Side-By-
Side Full, 2D + Depth, 2D + Depth + Graphics + Depth
Video Compliance
HDMI, HDCP, and CEC (Consumer Electronics Control)
Embedded Audio
Up to PCM 8 channel, Dolby Digital TrueHD, and DTS-HD Master Audio
Input DDC Signal
5.0 volts p-p (TTL)
Input Video Signal
0.5 to 1.0 volts p-p
IR Carrier Frequency Range
33-55kHz at 5 volts
RS232 Baud Rate
Up to 115200 baud
HDBaseT Signal Characteristics
Maximum Distance
60 m
Cable Requirements
Solid core shielded Category 5e, Category 6 or greater with TIA/EIA-568B crimp pattern
Bandwidth
10.2 Gbps
Gain
0 dB – 10 dB at 100 MHz
Resolution Range
800x600 – 1920x1200
Signal to Noise Ratio (SNR)
> 70 dB at 100 MHz over 100 m
Return Loss
< -30 dB at 5 KHz
Total Harmonic Distortion (THD)
< 0.005% at 1 KHz
Min-Max Signal Level
< 0.3 V – 1.45 Vp-p
Differential Phase Error
±10° at 135 MHz over 100 m
Chassis and Environmental
Enclosure
Painted steel
Dimensions
110mm x 76mm x 24mm (4.33 in x 2.99 in x 0.95 in)
Shipping Weight
0.5 kg (1.1 lbs.)
Operating Temperature (Environment)
0° to +40° C (+32° to +104° F)
Operating Temperature (Chassis)
31° C (88° F) (S); 38° C (100° F) (R)
Operating Humidity (Environment)
20% to 90%, Non-condensing
Storage Temperature (Environment)
-10° to +60° C (+14° to +140° F)
Storage Humidity (Environment)
20% to 90%, Non-condensing
Power, ESD, and Regulatory
Maximum Power Consumption
8 watts (S), 22 watts (R)
Power Supply (Not Included)
24vDC / 1.5 Amp
ESD Protection
15kV
Regulatory
CE, RoHS
Other
Standard Warranty
2 Years
Diagnostic Indicators
Link and power LEDs
DIGI-HD60C-R Compatible Transmitters
DIGI-HD70-S, DIGI-HD60C-S, DIGI-HDE-S, FLX-BO4A, DIGI-44B, DIGI-88B, ASW-WP, DIGI-P123,
DIGI-P52
DIGI-HD60C-S Compatible Receivers
DIGI-HD70-R, DIGI-HD60C-R, DIGI-HDE-S, FLX-BI4
Included Items
Installation Guide
Accessories
Power Supply
PS-24D-25
IR Emitter
DIGIB-EMT
IR Eye
DIGIB-EYE
Universal Mounting Bracket
DIGI-PMK1
