Validity
This document applies to products of the CDG025D and
CDG025D-S series.
Part numbers of standard products are indicated below. OEM
products have other part numbers and different parameter
settings (e.g. factory setting of setpoint) as defined in the
corresponding ordering information.
Flange
75 ⇒ 1000 (Torr only)
75 ⇒ 1100 (mbar only)
76 ⇒ 100
77 ⇒ 10
78 ⇒ 1
76 ⇒ 0.1
82 ⇒ 200
83 ⇒ 20
84 ⇒ 2
85 ⇒ 0.25
87
⇒ 500
3xx-x0x
0 ⇒ 1/2" tube
1 ⇒ DN 16 ISO-KF
2 ⇒ DN 16 CF-R
3 ⇒ 8 VCR female
7 ⇒ 4 VCR male
Measurement range
(F.S.)
Switching function
Unit
Without switching function
0
⇒ Torr (x 133 Pa; x 1.3 mbar)
2 ⇒ mbar (x 100 Pa)
With switching function
3
⇒ Torr (x 133 Pa; x 1.3 mbar)
5 ⇒ mbar
(x 100 Pa)
The part number (PN) can be taken from the product nameplate.
