10
tira90e1 (2014-01) RS232C.cp
Parameter name Data
type
Access
Right
Byte
Type
Byte
No. 1
Byte
No. 2
Byte
No. 3
Comment
SystemDateTime uint8 R Byte 0 0xE2 0x00 Set Date and Time.
W 0xF2
uint8 R Byte 1 0xE2 Format: dd.mm.yyyy hh:mm:ss
W 0xF2 e.g. 21/10/2013 10:41:00
uint8 R … 0xE2
W 0xF2
uint8 R Byte 19 0xE2
W 0xF2 (Last digit: null terminator)
EthernetLAN uint8 R 0xE2 0x14 0 Switch Ethernet LAN off
W 0xF2 1 Switch Ethernet LAN on
WirelessLAN uint8 R 0xE2 0x28 0 Switch Wireless LAN off
W 0xF2 1 Switch Wireless LAN on
WLANSettings uint8 R Byte 0 0xE2 0x51 TCP-IP Address of current wifi
connection
uint8 R Byte 1 0xE2 Format: IP-Adress|Network-Mask
uint8 R … 0xE2 Gauge resets after successful IP
change
uint8 R Byte 19 0xE2 (Last digit: null terminator)
LANSettings uint8 R Byte 0 0xE2 0x65
W 0xF2
TCP-IP Address of current LAN
connection
uint8 R Byte 1 0xE2
W 0xF2
Format: IP-Adress|Network-Mask
uint8 R … 0xE2
W 0xF2
Gauge resets after successful IP
change
uint8 R Byte 19 0xE2
W 0xF2
(Last digit: null terminator)
CustomAnalogOut uint8 R 0xE2 0x89 0 Switch Zoom for analog out off
W 0xF2 1 Switch Zoom for analog out on
AnalogoutPLow real32 R Byte 0 0xE2 0x81
W 0xF2
Low pressure threshold for zoom
function
R Byte 1 0xE2
W 0xF2
Will set this pressure value to 0.0V
R Byte 2 0xE2
W 0xF2
R Byte 3 0xE2
W 0xF2
AnalogoutPHigh real32 R Byte 0 0xE2 0x85
W 0xF2
IEEE Standard for Floating-Point
Arithmetic
R Byte 1 0xE2
W 0xF2
Will set this pressure value to 10.0V
R Byte 2 0xE2
W 0xF2
R Byte 3 0xE2
W 0xF2
Pressure real32 R Byte 0 0xE2 0x8B Pressure value in pressure units
R Byte 1 IEEE Standard for Floating-Point
Arithmetic
R Byte 2
R Byte 3
(continued)
