1.3 Technical Description
1.3.1 Configuration of Fieldbus nodes in
Profibus-DP
1.3.1.1 GSD File / Main Equipment File
Note
The GSD file is available in the internet.
The properties and capabilities of a Profibus-DP unit are
documented in the GSD-File. This is a file format which
is defined by the standard, so that manufacturer inde-
pendent project tools may be implemented for Profibus-
DP systems by various manufacturers. For operation of
the configuration software please refer to the correspon-
ding operation instructions provided by the manufacturer
of the configuration software.
1.4 Technical Data
The technical data as specified in the Operating Instruc-
tions for the PEG100 - tina14e1 apply. The following data
apply in addition to the Profibus-DP interface:
Supported Baud Rates:
9.6 k Baud
19.2 k Baud
93.75 k Baud
187.5 k Baud
500 k Baud
1.5 M Baud
Expanded User Parameter Data
5 bytes of parameter data are required.
Configuring
The number of input and output data is 2 bytes each.
Sync-Mode and Freeze-Mode
The sync-mode and the freeze-mode are supported.
1.5 Supplied Equipment
The supplied equipment is the same as detailed for the
PEG100 in Operating Instructions tina14e1. The follo-
wing items are supplied in addition:
- Profibus DP interface built into the PEG100,
PEG100-P Part Number 351-005
- Operating Instructions tina15e1
4
tina15e1-a (0206) PEG100-P.ga
for automatic baud
rate detection
