1 Description
1.1 General
The Penning Gauge PEG100-P is supplied
ready for operation. Even so, we recom-
mend to read these Operating Instructions
with care so as to ensure optimum operating
conditions right from the start.
These Operating Instructions contain important informati-
on on the functions, installation, start-up, operation and
troubleshooting of the Penning Gauge PEG100-P.
Important remarks concerning operational safety and
protection are emphazised as follows:
Warning Indicates procedures that must be strict-
ly observed to prevent hazards to per-
sons.
Caution Indicates procedures that must strictly
be observed to prevent damage to, or
destruction of the PEG100-P.
Note
Indicates special technical requirements that the user
must comply with.
The references to diagrams, e.g. (1/3), consist of the Fig.
No. and the item No. in that order.
Unpack the PEG100-P immediately after delivery, even
if it is to be installed at a later date.
Examine the packaging for any external damage. Com-
pletely remove all packaging materials.
Note
Retain the shipping container and the packaging materi-
als in the event of complaints about damage.
Check that the PEG100-P is complete
Carefully examine the PEG100-P visually.
If any damage is discovered, report it immediately to the
forwarding agent and insurer. If the damaged part has to
be replaced, please get in touch with the orders depart-
ment.
1.2 Purpose
1.2.1 Penning Gauge PEG100-P
The PEG100-P is equipped with the fieldbus interface
Profibus-DP. Automated process instruments can be lin-
ked easily.
1.2.2 Profibus-DP
The norm EN 50170 decribes the fieldbus system Profi-
bus-DP. Technical and functional features of the Profi-
bus-DP are specified here. The Profibus-DP distinguis-
hes between master and slave instruments. Master
instruments determine the data circulation. They trans-
mit data to their related slaves and request data from
them. It is possible to configure the fieldbus as a mono-
master or multi-master system.
The PEG100-P represents a slave unit which may recei-
ve different messages from the Profibus master and out-
put corresponding replies in response to the informati-
on/commands from the master. In a Profibus system up
to 126 units including the master may be operated. A cor-
responding slave address must be set up for the
PEG100-P.
1.2.3 Profibus-DP Master Configuration
Software
In order to configure the master together with the indivi-
dual slaves software packages are available from the
manufacturers of the master units.
3
tina15e1-a (0206) PEG100-P.ga
