10 tina86e1 (2013-11)
2 Technical Data
For further technical data for gauges with EtherCAT
interface →  [5].
Measurement range → "Validity"
Accuracy 1) 0.2% of measured value
Temperature effect on zero 0.0025% F.S./ °C
Temperature effect on span 0.02% of reading / °C
Resolution 0.003% F.S.
Gas type dependence none
Output signal analog
(measurement signal)
Measurement range 0 … +10 V
Voltage range –5 … +10.24 V
(limited to +10.24 V)
Relationship voltage-pressure linear
Output impedance 0 Ω (short-circuit proof)
Loaded impedance >10 k Ω
Response time
2) 30 ms
Identification
Resistance R
Ident
Voltage
13.2 k
Ω referenced to
supply common
≤5 V
Remote Zero Adjust
External switching contact
digital input for zero adjust-
ment (
→  25)
30 V (dc) / <5 mA (dc)
1)
Non-linearity, hysteresis, repeatability in the calibrated range at 25 °C
ambient operating temperature without temperature effects after
operation of 2 h.
2)
Increase 10 … 90 % F.S.R.
