tina60e1-a (2011-04) 13
RS232C / RS485 interface
Transmission rate
Data format 57600 baud (default)
binary
8 data bits
one stop bit
no parity bit
no handshake
→ "Power Connection"
For further information on the RS232C / RS485C interface
→ [3].
DeviceNet interface
Specification, data format,
communication protocol
→ [6]
Interface, physical CAN bus
Data rate (adjustable via
switch) 125 kBaud
250 kBaud
500 kBaud (default)
(125 kBaud,
250 kBaud, 500 kBaud
programmable via
DeviceNet,
→ [4])
Node address (MAC ID)
(Adjustable via 0 … 63dec (63dec default)
(0 … 63 programmable
via DeviceNet,
→ [4])
DeviceNet connector Micro-Style, 5-pin, male
Cable shielded, special DeviceNet
cable, 5 conductors
→ 32, → [7]
Cable length, system wiring according to DeviceNet
specifications,
→ [6], [7]
For further information on the DeviceNet interface → [4]
