INFICON PSG55x ATM to Medium Vacuum Gauge (RS232C / RS485C) - Manual (Page 8)

8
tira59e1 (2010-07) RS232C.cp
PID Name Description
Factory
setting Min. Max. Type
275 Setpoint 1 High Trip Point Setpoint High Trip Point in mbar 1500 5.00E-04 1500 Fixs32en20
276
Setpoint 1 High Trip Point
Enable
0 Off
1 On 1 0 1 Uint8
277 Setpoint 1 Low Trip Point Setpoint Low Trip Point in mbar 5.00E-05 5.00E-05 1500 Fixs32en20
278
Setpoint 1 Low Trip Point
Enable
0 Off
1 On 1 0 1 Uint8
279 Setpoint 1 Status Status of Relay 1 0 Uint8
281 Setpoint 1 ATM Factor
Factor for ATM setpoint
The atmospheric pressure is multiplied by
this factor and used as Setpoint 1. To
activate the ATM mode select the
Setpoint 1 mode.
1.1 0 3 Fixs32en20
282 Setpoint 2 High Trip Point Setpoint High Trip Point in mbar 1500 5.00E-04 1500 Fixs32en20
283
Setpoint 2 High Trip Point
Enable
0 Off
1 On 1 0 1 Uint8
284 Setpoint 2 Low Trip Point Setpoint Low Trip Point in mbar 5.00E-05 5.00E-05 1500 Fixs32en20
285
Setpoint 2 Low Trip Point
Enable
0 Off
1 On 1 0 1 Uint8
286 Setpoint 2 Status Status of Relay 1 0 Uint8
288 Setpoint 2 ATM Factor
Factor for the ATM setpoint
The atmospheric pressure is multiplied by
this factor and used as Setpoint 2. To
activate the ATM mode select the
Setpoint 2 mode.
1.1 0 3 Fixs32en20
455 Setpoint 1 Mode
Setpoint mode
0 Setpoint (Low / High Trip mMode)
4 Setpoint (Low / High Trip mode). In
addition, the setpoint adjustment
buttons are disabled.
1 The Low Trip Point is in ATM mode.
5 The Low Trip Point is in ATM mode. In
addition, the setpoint adjustment
buttons are disabled.
2 The High Trip Point is in ATM mode.
6 The High Trip Point is in ATM mode. In
addition, the setpoint adjustment
buttons are disabled.
3/7 Reserved function 0 0 7 Uint8
456 Setpoint 2 Mode
Setpoint mode
0 Setpoint (Low / High Trip mode)
4 Setpoint (Low / High Trip mode). In
addition, the setpoint adjustment
buttons are disabled.
1 The Low Trip Point is in ATM mode.
5 The Low Trip Point is in ATM mode. In
addition, the setpoint adjustment
buttons are disabled.
2 The High Trip Point is in ATM mode.
6 The High Trip Point is in ATM mode. In
addition, the setpoint adjustment
buttons are disabled.
3/7 Reserved function 0 0 7 Uint8
(continued)
Setpoints
