INFICON PSG55x ATM to Medium Vacuum Gauge (RS232C / RS485C) - Manual (Page 6)

6
tira59e1 (2010-07) RS232C.cp
PID Name Description
Factory
setting
Min. Max. Type
103 Reset
0 Write
The sensor carries out a reset.
1 Write
The sensor resets all parameters to their
factory settings.
104 Run Hours Operating hours [0.25 h] Fixs32en2
207 Serial Number Serial number 4294967295 Uint32
208 Product Name Product name PCG550 String
209 Manufacturers Name Name of manufacturer INFICON AG String
210
Manufacturers Model
Number
Model number String
218 Software Version Software version String
227 RS232 Baud Rate 9600, 19200, 38400, 57600 57600 9600 57600 Uint32
243 Display Direction
Display orientation
0 Setting for flange in bottom position
1 Setting for flange in top position 0 0 1 Uint8
PID Name Description
Factory
setting Min. Max. Type
223 Active Instance Number
Current sensor
1 CDG sensor active
2 Pirani sensor active
3 Mixed signal range Pirani and CDG
sensor active
Uint8
33000 Pirani Full Scale Pirani fullscale 1000 Fixs32en20
33001 Pirani Overrange Value Pirani overrange status output limit 1000 Fixs32en20
33002 Pirani Underrange Value Pirani underrange status output limit 5.00E-05 Fixs32en20
255 Pirani Safe State
Pressure reading in mbar that is output in
the event of an error in Pirani mode
0 0 mbar
1 1500 mbar
2 The last valid value is retained.
3 The Pirani Safe State value is output. 0 0 3 Uint8
256 Pirani Safe State Value
Pressure reading in mbar that is output in
the event of an error if the Pirani Safe State
is set to 3.
0 0 2047 Fixs32en20
417 Pirani Adjust Flag
Executes a manual Pirani sensor adjust-
ment.
Set the value to "1" in order for the adjust-
ment to be executed.
0 Uint8
236 CDG Safe State
*
Pressure reading in mbar that is output in
the event of an error in CDG mode.
0 0 mbar
1 1500 mbar
2 The last valid value is retained.
3 The CDG Safe State value is output. 0 0 3 Uint8
237 CDG Safe State Value
*
Pressure reading in mbar that is output in
the event of an error if the CDG Safe State
is set to 3.
0 0 2047 Fixs32en20
(continued)
General information
Sensor details
