INFICON - Operating Instructions EXTRIMA
Certificate:
1981011
Master Contract:
241576
Project:
2531732
Date Issued:
July 17, 2012
DQD 507 Rev. 2012-05-22 Page: 2
SPECIAL CONDITIONS FOR SAFE USE “X”
Battery Charger must be CSA Certified (or equivalent), with a maximum charging voltage of 12.6 V and a
maximum charging current of 770 mA.
Notes:
APPLICABLE REQUIREMENTS
CAN/CSA-C22.2 No. 0-M91 General Requirements – Canadian Electrical Code, Part
II
CAN/CSA-C22.2 No. 60079-0:07 Electrical apparatus for explosive gas atmospheres -
Part 0: General Requirements
CAN/CSA-E60079-11:02 Electrical apparatus for explosive gas atmospheres -
Part 11: Intrinsic Safety "i"
CAN/CSA-C22.2 No. 60529:05 Degrees of protection provided by enclosures (IP Code)
ANSI/UL 60079-0:09 Electrical Apparatus for Explosive Gas Atmospheres -
Part 0: General Requirements
ANSI/UL 60079-11:09 Electrical apparatus for Explosive Gas Atmospheres -
Part 11: Intrinsic Safety “i”
ANSI/IEC 60529:2004 Degrees of Protection Provided by Enclosures (IP
Code)
MARKINGS
For the Extrima Detector and CX21 cable the following markings are provided on a min 0.02 in thick metal
nameplate, secured to the enclosure with adhesive (Refer to Drawing 1421). For the Probe the following
markings are produced by a laser-engraving method printed directly on the side of the aluminum handle:
Extrima Detector
- CSA Monogram with C US Indicator;
- Company name;
- Model number;
- Serial number or Date Code (appears on a separate nameplate);
- Certificate reference (“CSA 2007 1981011 X”)
