Page 11
11
EN
INFICON - Maintenance manual Sensistor XRS9012
1.3 Product
information
Touch pad keyboard
Front cover
Rubber seal
Loudspeaker
Circuit board
Battery
Battery holder
Front panel screw
Rubber seal
Back cover
Serial number label
Product facts:
Sensitivity: 0,7ppm H2 in air
Response time: < 1sec
Start-up time: 6 sec
Outputs:
- Display 10 level LED bar
graph
- Speaker 5-1600 Hz
- Earphones std earphones, 3,5mm
jack, > 8ohm
Power Supply: Rechargeble lead
batteries
Battery capacity: 13h @ 20o C
Protection: IP55
Size & weight: 250x120x85 mm, 1,9kg
260x220x95 mm, 2,5 kg
(incl. carrying case)
