Hydrogen leak detector Sensistor ISH2000 - Operating Instructions
40 OP-Sensistor ISH2000-EN-201203
EN
8.16 Default parameters
Table 8-14. Range and default settings of all Sensistor ISH2000 parameters.
Parameter Range Default
Analysis Unit Several Choices PPM
APC Time A 0.0 - 6000.0 s 10.0 s
APC Time B 0.0 - 6000.0 s 0 s
APC Time C 0.0 - 6000.0 s 0 s
APC Time D 0.0 - 6000.0 s 0 s
Audio Base Frequency Several Choices 400 HZ
Auto Range ON/OFF ON
Audio Ready Pulse ON/OFF ON
Audio Threshold
(Detection) 0 - 100% 0%
Audio Threshold
(Analysis) 0 - 100% 4%
Brightness 0 - 21 21
Calibration Time Min Calibra. Time-30 s 10 s
Calibration Tolerance 0-100% 25%
Clock hh:mm:ss -
Contrast 0-20 10
Correlation Values 1.00E-37 - 1.00E+37 1.00E+00 = 1
Date YY-MM-DD -
Debug Mode ON/OFF OFF
Detector Signal Level 0 - 100% 20%
Direct sensitivity
adjustment ON/OFF ON
Display Threshold 0 - 100% 4%
Invert Colors ON/OFF OFF
Language Several choices English
Measure/Print Button ON/OFF OFF
Min Calibration Time 0 - 30 s 5 s
Min Presentation Time 120 s 1 s
Multipoint Analysis Several Choices OFF
Multipoint Analysis Time 0.0 - 30.0s 5.0s
Number of significant
Digits 2/3 2
Password Max 12 characters “” = No password
Password protected
calibration ON/OFF OFF
Printer Port Several choices No Printer
