Hydrogen leak detector Sensistor ISH2000 - Operating Instructions
36 OP-Sensistor ISH2000-EN-201203
EN
The data format for Detection data output contains of ten ASCII characters. Nine
characters show the value in engineering format (See “Engineering format” on
page 17), and one character shows linefeed (LF).
The print time is 50Hz continuous streaming data.
Note: Data rate is 25Hz when Sensistor ISH2000 is running in Service Display Mode .
RS232 serial communication
The most commonly used Sensistor ISH2000 functions can be started/configured
over the RS232 interface.
Table 8-10. RS232 communication specifications.
RS232 interface commands
Table 8-11. Common used functions.
K = Calibration request
Starts calibration if the Sensistor ISH2000 has an active probe driver installed.
Sensistor ISH2000 answers with a "K" if an active driver containing a calibration
routine was found and "F" if the calibration APC sequence not found. Calibration
doesn’t start if Purge level is reached.
M = Measure Request
Parity None
Flow control None
Setting Value
Setting No Printer PC Printer
Data
Output
Data rate 115200 baud 1200 baud 9600 baud
Data bits 8 8 8
Stop bits 1 1 1
Parity None None None
Flow control None None None
Command Header
Calibrate K
Measure M
Print Request N
Stop Measurement Q
Hand Probe R
Active Probe (Installed AP) S
Analysis Mode X
Detection Mode Z
Combined Mode Y
