A/B Transient Operation Tutorial
Panel Operations VFD Display
1.
Power on the electronic load.
Self-test
2.
Press  keys to select the channel to be edited. In this example, we
select channel 1.
CH01 CC OFF
Vdc = 0.0000V
Adc = 0.0000A
Wdc = 0.00W
3.
Press Setup to enter the channel setup menu. Select and
press Enter to change the operating mode to CC mode. Press Enter to
confirm.
CH01
Mode=CC
RANGE=HIGH
Iset=9.000A
4.
Press  key to select setting and press Enter. Then press 
key to select LOW RANGE and press Enter to confirm.
CH01
HIGH RANGE
LOW RANGE
5.
Press  key to select the rise slope setting <∫> and press Enter. For
1A/us, input 1 and press Enter to confirm.
CH01
Rise Speed Set
= 1.00A/Us
6.
Press  key to select the fall slope setting <∫> and press Enter. For
2A/us, input 2 and press Enter to confirm.
CH01
Fall Speed Set
= 2.00A/Us
7.
Press  key to select A level setting and press Enter. For
10A, input 10 and press Enter to confirm.
CH01
Transition A
Level = 10.00A
8.
Press  key to select A width setting and press Enter. For 0.002s,
input .002 and press Enter to confirm.
CH01
Tran. A Width =
0.002S
9.
Press  key to select B level setting and press Enter. For 2A,
input 2 and press Enter to confirm.
CH01
Transition B
Level = 2.00A
10.
Press  key to select B width setting and press Enter. For 0.003s,
input .003 and press Enter to confirm.
CH01
Tran. B Width =
0.003S
11.
Press  key to select transient operation mode and press
Enter. Select Continuous and press Enter key to confirm.
CH01
Continuous
Pulse
Toggle
