Setting CV, CC, CR, CW, CZ Mode
The following procedure will show you a basic example of how to set up your operation mode from
the front panel.
Panel Operations VFD Display
1.
Power on the electronic load.
Self-test
2.
Press  keys to select the channel to be edited, such as channel 1.
CH01 CC OFF
Vdc=0.0000V
Adc=0.0000A
Wdc=0.00W
3.
Press Setup key to enter the channel setup menu, press Enter key to
enter the selection menu and press  key to select CV, CC, CR,
CW, or CZ mode. Press Enter key to confirm.
CH01
Mode=CC
RANGE=HIGH
Iset=9.000A
4.
Press  key to select selection menu. Press Enter key to enter
the selection menu and press  key to choose or
. Press Enter key to confirm.
CH01
HIGH RANGE
LOW RANGE
5.
Press  key to select the voltage setting , current setting ,
resistance setting , power setting, or impedance setting and press
Enter key to confirm.
CH01
Const Current
Set= 1.25A
6.
Press  key to select the rise slope setting <∫>. Input value and press
Enter key to confirm. (CC mode only)
CH01
Rise Speed Set
= 1.00A/Us
7.
Press  key to select the fall slope setting <∫>. Input value and press
Enter key to confirm. (CC mode only)
CH01
Fall Speed Set
= 2.00A/Us
8.
Press Esc key to exit.
9.
Press On/Off key to turn on the load’s input.
CH1 CC ON
Vdc=0.0000V
Adc=0.0000A
Wdc=0.00W
