SPECIFICATIONS
power dissipation (nom. load) RZR 2051 control P = 80 watts
power dissipation (nom. load) RZR 2052 control
RZR 2102 control
RZR 2102 control Z P = 140 watts
P = 140 watts
P = 140 watts
power rating, motor, RZR 2051 control P = 50 watts
power rating, motor, RZR 2522 control
RZR 2102 control
RZR 2102 control Z P = 100 watts
P = 100 watts
P = 100 watts
dimensions (in mm) RZR 2051 control 72 wide; 206 high; 176 deep
dimensions (in mm) RZR 2052 control
RZR 2102 control 82 wide; 211 high; 176 deep
dimensions (in mm) RZR 2102 control Z 82 wide; 292 high; 176 deep
weight RZR 2051 control 2.8 kg
weight RZR 2052 control 3.7 kg
weight RZR 2102 control 3.7 kg
weight RZR 2102 control Z 4.7 kg
operating temperature 0 – 40 °C
storage temperature - 20 to + 80 °C
relative humidity 95 % (avoid reaching dewpoint)
protection class IP 40
Torque refer to graphs below
speed range
RZR 2051 control
RZR 2052 control
RZR 2102 control
RZR 2102 control Z
50
– 2000 rpm
30 – 1000 rpm
step 1: 12 – 400 rpm
step 2: 60 – 2000 rpm
step 1: 4 – 108 rpm
step 2: 17 – 540 rpm
serial interface RS 232
analog interface, (OUT), 0 – 10 volts
torque and speed
interface extension (IN)
4
– 20 mA; 0 – 10 volts
speed and speed range (optional)
remote control ON/OFF (optional)
stirrer coupling RZR 2051 control, RZR 2052 con-
trol and RZR 2102 control 10,5 mm chuck, drive shaft features bore to hold tool shafts
of up to 10 mm dia.
stirrer coupling RZR 2102 control Z 10,5 mm chuck, drive shaft don’t features bore to hold tool
shafts.
stirrer attaching system 13 mm dia. Rod (stand)
motor protector thermal circuit breaker disconnects motor in an overload
situation (permanent cut-off);
RESET with ON/OFF key
pilot light, „item ON“ power switch (GREEN)
shaft guard fits shaft guard (optional)
BCI/TVI suppression complies with EN 50081
operational mode 100% continuous
display 8-digit LCD, 2 lines, 5.6 mm high characters
measuring range, display 4 – 2000 rpm / 0-700 Ncm
Resolution 1 rpm / 0,1 Ncm
