51
E
GLASS-SET - R 15-300-006-21
components
A
15-300-001-11 condenser, T auto (R) *
B 15-300-002-31 vacuum fitting
C 15-300-002-58 distributor, includes valve (control)
C1 15-300-002-57 valve GL25/165
E 15-300-002-29 vapor tube, ground
F 15-300-003-17 evaporator flask, 20 l
H 15-300-004-11 collecting flask, 10 l, features bottom drain
H1 15-300-002-56 valve GL25/125 lg.
I 15-300-002-54 inlet pipe
I1 04-03-01-06-02 hose, PTFE 6.5x0.5
N 11-300-003-25 GL25 coupling kit
O 15-300-002-45 valve GL18
P 11-300-005-22 nipple for GL14
Q 23-09-03-01-27 coupling ring GL14
R 23-30-01-02-64 nipple for GL18
S 23-09-03-01-23 coupling ring GL18
T 23-09-03-01-24 screwed cap GL18
U 11-300-002-94 threaded joint KS 64, coated
V 11-300-002-95 flask clamp for S40/S41
W 23-30-01-01-09 sandwich gasket 50 / 69 / 3
X 23-30-01-03-31 spacer sleeve
Z 15-300-001-08 condenser
Use this list when checking your shipment for completeness.
B
R,S
T,T1
O
I,I1,N,X
P,Q
Z
V
H,H1
H,H1
U
A
C1
T
C,E,W
F
