Heidolph LABOROTA 20 eco - Manual (Page 43)

43
E
LABOROTA 20 eco SPECIFICATIONS
Supply voltage 3 x 400 V 50 Hz or 3 x 230 V 60 Hz
or 1 x 230 V 50/60 Hz
Power rating 4.300 VA
Rotation speed (electronic control) 6 - 160 1/min
Heating bath 400 mm dial., stainless steel V2A
Water bath level regulation via water feed as per the overflow principle
Temperature range heating bath 25 - 180 ° C
Heating power 4000 watts
Bath lift motorized
Over temperature & dry
running protection
separate safety circuit
Evaporator flask 20 , 10, or 6 liters optional
Collecting flask 10 liters, features bottom drain valve
Pumping capacity required (vacuum 2.5 - 5 m
3
/h (vacuum pump is optional)
pump)
Cooling water consumption 150 - 250 l / h (depending on glass set)
Dimensions ( width x depth x height ) 970 mm x 620 mm x 1600 mm
(with front panel protrusion: 690 mm)
Ambient conditions 0 – 40°C at max. 80% rel. humidity
Weight approx. 100 kg (does not include glass set)
Illustration including substructure 591-23300-00
