Page 6 of 12 General Machine Products Co., Inc.
3. SPECIFICATIONS
Cable Diameter Range: 9 - 20mm
The maximum diameter of a new cable for installation is depend-
ent on the diameter of the existing cable and the duct size.
Duct Size: 1 1/4" SDR
Installation Principle: Viscous Drag
Max Operating Pressure: 175 psi (12 Bar)
Length: 12" (305mm)
Width: 6" (152mm)
Height: 3" (76mm)
Weight: 9 lbs. (4kg)
Min Flow Acceptance: 250 cfm (7m³/min)
