Important!
Ì In the case of series connection of more than 11 devices, the PFH
d
can be
calculated according to one of the stated methods in EN ISO 13849-1:2008,
Section 4.5.1.
Ì If the simplified method according to Section 6.3 of EN ISO 13849:2008-12
is used for validation, the Performance Level (PL) might be reduced when
more than 11 devices are connected in series.
Ì It is only allowed to use components that are permissible in accordance with
the table below.
Possible combinations for CES components
Safety switch
Actuator
Door hinge right
CES-A-BLN-R2-100776
100776
Door hinge left
CES-A-BLN-L2-104510
104510
Usage independent of
position of door hinge
CES-A-BLN-U2-103450
103450
Usage independent of
position of door hinge
CES-A-BDN-06-104730
104730
Door hinge right
CES-AR-CR2-CH
Door hinge left
CES-AR-CL2-CH
Key to symbols Combination possible
Note!
Devices with version number V 1.1.2 or higher can be operated on an AR evalua-
tion unit. Please refer to the operating instructions for the relevant AR evaluation
unit for more information.
