Bunn DUAL TM (Serial # DUAL010000 - Up) 27040.0000F User Manual
Page 23

Page 23
SERVICE (cont.)
Location:
The electronic control assembly (1) is located
inside the lower left front on the component bracket of
the brewer. Access will also be needed to the tempera-
ture sensor (8), liquid level probe (7) located on the
tank lid and to the triac assembly (17) located beneath
the tank.
General:
This system controls the liquid level and water
temperature of the brewer. These two functions act
independently of each other and should be tested
separately.
ELECTRONIC CONTROL ASSEMBLY
!
CA
UTIO
N
HO
T W
AT
ER
.
MINU
TES
BU
NN-O
-M
ATIC
P/N 262
0- 1
20 VAC
.
MIN
UTES
BUN
N-O-M
ATIC
P/N 2620- 120 V
AC
