Read head CES-A-LMN-SC
Ì
Cylindrical design M12
Ì
M8 plug connector (snap-action and screw terminals)
Dimension drawing
Note
The read head is allowed to be installed as a maximum up to the clear zone (area
of the active face without metal housing).
Typical operating distance
With evaluation unit CES-A-AEA... and actuator CES-A-BMB
Note
A minimum distance of s = 1.2 mm must be maintained.
Approvals
17
5
32 19,
7
R eading distance s
C
entre offset
m
connected
35
4
8
30
M12
x1
M8x
1
37
1)
1)
Active face
1) Clear zone (area of the active face without metal housing)
-4 -6 -2 0
Centre offset m [mm]
Distance s [mm]
OFF
ON
Switch-on
distance
ON
OFF
Hysteresis
Distance s S ao
Output state
Switch-off
distance
OFF
-8 2 8 6 4
2
4
6
8
Actuator
Read
head
s
m
not permissible area not permissible area
Hysteresis
