Operating Instructions Safety System CES-A-AEA-02B/CES-A-AEA-04B
25
Read head CES-A-LNA...
Cube-shaped design 42 x 25 mm
Ì
Hard-wired cable
Dimension drawing
Typical operating distance
With evaluation unit CES-A-AEA... and actuator CES-A-BBA
Note
For a side approach direction for the actuator and read head, a minimum distance
of s = 3 mm must be maintained so that the operating distance of the side lobes
is not entered.
Pin assignment
Read head with connection cable
Approvals
CES-A-L XXXXXX
25
8 4,
5
42
32 ±0,1
12
4,6
"l"
2 safety screws M4 x 14
are supplied
Active face Active face
Side
lobe
N
-10 -15 -5 0
Centre offset m [mm]
Distance s [mm]
OFF
ON
Switch-on
distance
ON
OFF
Hysteresis
Distance s S
ao
Output state
Switch-off
distance
OFF
Hysteresis
-20 5 20 15 10
5
10
15
20
Side
lobe
N
Actuator
Read head
s
m
H11 H12 SH1
BN
WH
Screen
Read
head
Evaluation unit
CES-A-AEA...
