User Interface
User Interface
The software has been designed to present a consistent graphical user interface and so it is worth familiarising
yourself with the layout of the main window before proceeding further:
Main toolbar
The buttons on the left of the main toolbar provide overall control of your Touch Editor project. Create new
projects , open existing projects and save your work using the file management buttons. Use the Undo/Redo but-
tons to step backwards and forwards through operations that affect your project. Pages can be added , copied,
moved up and down in the page browser and deleted . The zoom buttons give you control of the Page Preview.
The final buttons on the toolbar provide access to the Theme Editor , Project Properties , Preferences, Help and
information About the software.
Page Browser
The Page Browser, located at the left of the screen, displays all pages that exist within the project. Selecting a
page will display it in the Page Preview screen and allow page properties to be adjusted in the Property Editor.
Page Preview
The Page Preview area is located in the centre of the window. Any selected page will be displayed in the Page
Preview window. Selecting the page or items on the page allows individual properties to be adjusted in the Prop-
erty Editor.
Property Editor
The Property Editor displays adjustable properties for any page items that are selected in the Page Preview win-
dow. The page, page switchers, buttons, sliders, colour pickers and keypads all have user-configurable prop-
erties.
