Selador Series User Manual
Specifications
N o t e :
Vivid-R replaces the original Vivid fixture as of February 2010. The manufacturer of the
K2 LED emitter is phasing out these emitters over the next year. Vivid-R maintains
photometrics equivalent to the original Vivid with higher intensity and uses less power.
Physical
• Rugged extruded anodised aluminum construction
• Yoke, trunnion (floor stand), or pipe-hanger mounting
options
• Advanced thermal management systems for long LED
life
• Available in black
• 0 to 40°C ambient operating temperature
• See
• Available in 279, 546, 1080 and 1613mm lengths
• See
• On-board fan speed control for no-noise operation
unless in high ambient temperature situations.
(Fixtures built January 2010 and after)
Electrical
• 100V to 240V 50/60 Hz internal power supply
• 1.5m power lead supplied
• Neutrik
®
PowerCon
®
input connector
• Requires power from non-dim source
LEDs
• Luxeon
®
Rebel™ 2.5W LED emitters (Lustr, Paletta,
Vivid-R, Vivid Fire, Vivid Ice, and Pearl)
• 50,000 hr. LED life
• Luxeon K2 3.5W LED emitters (original Vivid fixtures
manufactured before February 2010.)
• See
Note About LED Fixtures, page 3
Optical
• Integral 16° field angle optic (Pearl)
• Integral 18° field angle optic (original Vivid)
• Integral 19° field angle optic (Vivid-R)
• Integral 26° field angle optic (Lustr, Paletta, Vivid Fire
and Vivid Ice)
• Combine secondary lenses for desired beam spread
• Slots for secondary lenses
Colour
• Selador Seven-color x7 LED products for superior
broad spectrum colour mixing
– Lustr – Optimized for highest output in white and
light tints in a 7-color fixture
– Paletta – Optimized for strong, saturated colours
– Vivid, Vivid-R – Optimized for strong, saturated
colours at maximum brightness
• Interacts seamlessly with conventional sources
• Achieves excellent 3200° or any other Correlated
Colour Temperature white light from 800 to 20,000°K
(except Vivid Fire, Vivid Ice, and Pearl)
• Beautifully illuminates skin tones and other objects
• Deeply saturated colours across an exceptionally wide
gamut
• Selador special purpose LED fixtures
– Vivid Fire – Optimized for high-intensity saturated
colours on the red end of the spectrum
– Vivid Ice – Optimized for high-intensity saturated
colours on the blue end of the spectrum
– Pearl – High output warm and cool white LEDs for
variable colour temperature white (only) light output
• Colour rendering as high as 90 CRI (except Vivid Fire,
Vivid Ice, and Pearl)
