IMPORTANT: Do not lift hydraulic equipment by the
hoses or swivel couplers. Use the carrying handle or
other means of safe transport.
CAUTION: Keep hydraulic equipment away from
flames and heat. Excessive heat will soften packings
and seals, resulting in fluid leaks. Heat also weakens
hose materials and packings. For optimum performance do
not expose equipment to temperatures of 65°C [150°F] or
higher. Protect hoses and cylinders from weld spatter.
DANGER: Do not handle pressurized hoses. Escaping
oil under pressure can penetrate the skin, causing
serious injury. If oil is injected under the skin, see a
doctor immediately.
WARNING: Only use hydraulic cylinders in a coupled
system. Never use a cylinder with unconnected
couplers. If the cylinder becomes extremely
overloaded, components can fail catastrophically causing
severe personal injury.
WARNING: BE SURE SETUP IS STABLE BEFORE
LIFTING LOAD. Cylinders should be placed on a flat
surface that can support the load. Where applicable,
use a cylinder base for added stability. Do not weld or
otherwise modify the cylinder to attach a base or other support.
Avoid situations where loads are not directly centered
on the cylinder plunger. Off-center loads produce
considerable strain on cylinders and plungers. In
addition, the load may slip or fall, causing potentially
dangerous results.
Distribute the load evenly across the entire saddle
surface. Always use a saddle to protect the plunger.
IMPORTANT: Hydraulic equipment must only be
serviced by a qualified hydraulic technician. For repair
service, contact the Authorized ENERPAC Service
Center in your area. To protect your warranty, use only
ENERPAC oil.
WARNING: Immediately replace worn or damaged
parts by genuine ENERPAC parts. Standard grade
parts will break causing personal injury and property
damage. ENERPAC parts are designed to fit properly and
withstand high loads.
®
Model No. Description Item #2 Item #3 Item #4 Item #5 Item #7
Press Cylinder Pump Hose Pump Table Bolster Pin
VLP-506P802 50 ton RC506 P-802 HC-7206 DC3607950SR DQ1572061SR
VLP-506ZE5S 50 ton RR506 ZE5410SW-S HC-7206 (Qty. 2) DC3607950SR DQ1572061SR
VLP-506ZE5C 50 to RR506 ZE5410CW-S HC-7206 (Qty. 2) DC3607950SR DQ1572061SR
VLP-5013ZE5S 50 ton RR5013 ZE5410SW-S HC-7206 (Qty. 2) DC3607950SR DQ1572061SR
VLP-1006ZE3C 100 ton RR1006 ZE3410CW HC-7206 (Qty. 2) DC3607950SR DQ1577061SR
VLP-1006ZE3S 100 ton RR1006 ZE3410SW HC-7206 (Qty. 2) DC3607950SR DQ1577061SR
VLP-10013ZE3S 100 ton RR10013 ZE3410SW HC-7206 (Qty. 2) DC3607950SR DQ1577061SR
VLP-20013ZE3S 200 ton RR20013 ZE4420SW HC-7206 (Qty. 2) DC3607950SR BSS5383D
TABLE 1 - (SEE FIGURE 1)
