Chapter 5: Installation
The Gold DC Trombone must be installed in a suitable environment and properly connected to its
voltage supplies and the motor.
5.1 Unpacking the Drive Components
Before you begin working with the Gold DC Trombone, verify that you have all of its components, as
follows:
• The Gold DC Trombone servo drive
• The Elmo Application Studio (EAS) software and software manual
The Gold DC Trombone is shipped in a cardboard box with Styrofoam protection.
To unpack the Gold DC Trombone:
1.
Carefully remove the servo drive from the box and the Styrofoam.
2. Check the drive to ensure that there is no visible damage to the instrument. If any damage
has occurred, report it immediately to the carrier that delivered your drive.
3. To ensure that the Gold DC Trombone you have unpacked is the appropriate type for your
requirements, locate the part number sticker on the side of the Gold DC Trombone. It looks
like this:
Figure 1: Gold DC Trombone Part Number Sticker
4. Verify that the Gold DC Trombone type is the one that you ordered, and ensure that the
voltage meets your specific requirements.
The part number at the top provides the type designation. Refer to the appropriate part
number in the section Catalog Number at the beginning of the installation guide.
