Gold DC Trombone Installation Guide
MAN-G-DCTROIG-EC (Ver. 1.900)
||Technical Data for the 800 V Type| www.elmomc.com
10
Table of Contents
4.3 Technical Data for the 800 V Type
Feature Units 8/800 12/800 R11/800 R16/800
Minimum supply voltage
VDC A, H, S, or T Option in P/N*: 95+
Nominal supply voltage
VDC 560 for 400 VAC
680 for 480 VAC
Maximum supply voltage
VDC 780
Maximum continuous power
output
kW 5 7.5 7 10
Efficiency at rated power (at
nominal conditions)
% > 98
Auxiliary supply voltage option VDC
18 V to 30 V
Only for Control Supply A/H/S/T Option
Models
Auxiliary power supply
VA 7
Continuous current limit (Ic)
Amplitude sinusoidal/DC
trapezoidal commutation
A 8 12 11 16
Sinusoidal continuous RMS
current limit (Ic)
A 5.7 8.5 7.8 11.3
Peak current limit
A 2 x Ic No peak
*See section Catalog Number for details on the part number. The A, H, S, or T Option appears in
models where there is a 24 V control supply. If there is a 0 or 1 Option, the control power supply
operates from the main power.
Note on current ratings: The current ratings of the Gold DC Trombone are given in units of DC
amperes (ratings that are used for trapezoidal commutation or DC motors). The RMS (sinusoidal
commutation) value is the DC value divided by 1.41.
