Page 5
II. S
YSTEM
F
EATURES
Optional SM-1250E or SM-1250BE
Fog Nozzle and 282-A or 282-B
Stream Shaper
8500-01 and 8593-01
have Continuous 360
Electronic Travel Limits.
8500-01 EXT and
8593-01 EXT have
a 180 Horizontal Rotation
°
°
Horizontal Rotation
and Field Programmable
Fully Vaned Cast
Aluminum Waterway
Unique Dual Speed
Horizontal Travel for
Increased Aiming Accuracy
3” 150# ANSI Flange
4” 150# ANSI Flange
or 3” NPT - 8500-01 &
8500-01 EXT
*Simple 2 Wire
Installation
Billions of
Security Code
and Frequency
Combinations
Up to 1/4 Mile
Range
Remotely Programmable
Oscillation Function
RF Receiver
Control Module
*3rd wire provided for optional customer provided stow indicator lamp.
and
Figure 1
8500-01 w/282-A Stream Shaper and SM-1250E Nozzle
