NOTE – All six programming steps must be completed otherwise the changes will not
be stored to permanent memory!
(1)
Move the monitor to the left/right stow position. Hold the Red
Programming Button (see
) on the controller board until the
programming LED flashes on (approx 5 seconds).
(2)
Press and release the Red Programming Button on the controller board
again. The programming LED should flash once.
(3)
Press and release the Red Programming Button again. The programming
LED should flash twice.
(4)
Press and release the Red Programming Button a fourth time. The
programming LED should flash rapidly several times. (NOTE - There are no limits
stored in memory at this time and the monitor is capable of rotating 360º)
(5) To program the vertical stow position set switch A position 1 to “ON” for
stow up or to “OFF” for stow down (Receiver only). NOTE: The up/down
stow position will either be all the way up or all the way down, nowhere in
between.
(6) Remove power from the monitor for a minimum of 5 seconds. Reapply
power and operate the monitor to verify that the monitor will rotate
360º
continuously and stows correctly. (If the unit does not perform correctly
repeat steps 1 through 6.)
Keep this Installation Manual in a secure place so the settings can be retrieved if needed.
