Page 14
IV. C
ONTROL
S
YSTEM
S
PECIFICATIONS
Handheld Transmitter Specifications

Input power 2 AA batteries (Alkaline recommended)

Output power Meets FCC part 15 requirements for license free
operation

Transmitter dimensions
6” x 3 1/4” x 1 3/8”

Transmitter weight 10 ½ oz.

Operating temperature range -40

F to 150

F (-40

C to 65

C)

FCC ID QT8PTSS2011
Transmitter Specifications

Input power 12/24 VDC (11VDC to 30 VDC)

Output power Meets FCC part 15 requirements for license free
operation

Transmitter dimensions
7 5/8” x 3 7/8” x 2 3/8”

Operating temperature range -40

F to 150

F (-40

C to 65

C)

FCC ID QT8PTSS2011
Receiver Specifications

Power requirements W/O Converter Assembly 12VDC (11 to 14VDC)
With Converter Assembly (11-30VDC)
at the controller under full load

Control current 0.07 A *

Operating temperature range -40

F to 150

F (-40

C to 65

C)
Table 1
Motor Current Specifications
Monitor Left/Right Up/Down Nozzle
Run I 3 A 3 A 0.5 A
Stall I 12 A 14 A NA
Current Trip Point 12.5 A 8.0 A 4 A
Shock:

30 G's (55 Hz. @ .2 inch double amplitude)
Vibration:

15.5 G's (55 Hz. @ .05 inch double amplitude) continuous operation
Drop Test:

The handheld transmitter must meet operating specifications after drop from 1-meter height onto concrete
surface.
Environmental:

All enclosures have a NEMA 4 rating (must withstand a 1 inch stream of water (65 gpm) from a distance of
ten feet for five minutes, with no water entering the enclosure).
* All current ratings are at 12 volts
