EDITING SHOW PARAMETERS

(CONTINUED)

Software record lockout

In addition to the hardware jumper record lockout feature, the Rerun Architectural has a software record
lockout feature. When the software record lockout is enabled, no shows can be recorded and no parameter
data can be modified. The hardware record lockout jumper takes precedence over the software record
lockout. If the hardware record lockout jumper is removed, no data can be altered regardless of the state of
the software record lockout feature.

To alter the software record lockout status, do the following:

1.

Start playing any show.

2.

Pause the show at any point.

3.

Press and hold the number 10 [SHOW] button. Hold the number 10 [SHOW] button for about five
seconds. While held, the remaining [SHOW LEDS] will indicate the status of other show and system
parameters. The number 1 [SHOW LED] indicates the status of the software record lockout output
option. While continuing to hold the number 10 [SHOW] button, press the number 1 [SHOW] button
to toggle the state of the option. When the number 1 [SHOW LED] is lit, the Rerun Portable will not
allow any show or parameter data to be changed. When the number 1 [SHOW LED] is off, the
Rerun Portable will allow changes to be made. Set the software record lockout option as desired.

4.

Release the number 10 [SHOW] button.

5.

Press the [PAUSE] button to save the new settings and to resume the show.

Note:

!

The software record lockout feature is a global system parameter. Although it can be accessed
from any show, there is only one record lockout state.

!

By default, the hardware lockout jumper is installed (recording enabled), and the software record
lockout feature is disabled (recording enabled).

!

The hardware record lockout jumper must be installed for the software record lockout to have any
effect on the system.
