3.1
95-8620
10
DeVice repAir AnD retUrn
Prior to returning devices, contact the nearest local
Detector Electronics office so that a Return Material
Identification (RMI) number can be assigned. A
written statement describing the malfunction must
accompany the returned device or component to
assist and expedite finding the root cause of the
failure
.
Pack the unit properly. Always use sufficient packing
material. Where applicable, use an antistatic bag as
protection from electrostatic discharge.
NOTE
Inadequate packaging that ultimately causes
damage to the returned device during shipment
will result in a service charge to repair the damage
incurred during shipment.
Return all equipment transportation prepaid to the
factory in Minneapolis.
NOTE
It is highly recommended that a complete spare
be kept on hand for field replacement to ensure
continuous protection.
orDerinG informAtion
Sensor module, Transmitter module and termination
boxes (if used) must be ordered separately.
Refer to the UD20 Model Matrix for ordering details.
REplACEmENT pARTS
part Number Description
009700-001
Magnetic Tool
009793-002
Electronics Module
010253-001
250 ohm Terminating Resistor Kit
101197-001*
Stop Plug, 3/4" NPT, AL
101197-004*
Stop Plug, 3/4" NPT, SS
101197-005
Stop Plug, M25, AL, IP66
101197-003
Stop Plug, M25, SS, IP66
010816-001
Stop Plug, 20PK, 3/4" NPT, AL, EX D
010817-001
Stop Plug, 20PK, 3/4" NPT, SS, EX D
010818-001
Stop Plug, 20PK, M25, AL, IP66, EXDE
010819-001
Stop Plug, 20PK, M25, SS, IP66, EXDE
102804-001
Reducer, M25 to M20, AL
102804-003
Reducer, M25 to M20, SS
103922-001
475 Field Communicator
005003-001
Lubriplate grease, 1 oz.
* NEMA 4/IP66 rating requires addition of non-hardening
thread sealant or Teflon tape.
ASSISTANCE
For assistance in ordering a system to meet the needs
of a specific application, contact:
Detector Electronics Corporation
6901 West 110th Street
Minneapolis, Minnesota 55438 USA
Operator: (952) 941-5665 or (800) 765-FIRE
Customer Service: (952) 946-6491
Fax: (952) 829-8750
Web site: www.det-tronics.com
E-mail: [email protected]
mODEl
DESCRIpTION
UD20
Universal Display Unit
TypE
mATERIAl
A
Aluminum
S
Stainless Steel (316)
TypE
THREAD TypE
5m
5 PORT, METRiC M25
5N
5 PORT, 3/4” NPT
TypE
OUTpUTS
26
Pass-Through 4-20 mA, HART
TypE
AppROvAl
w
FM/CSA/ATEX/CE/iECEx
b
iNMETRO (Brazil)
TypE
ClASSIfICATION (Div/Zone)
2
Ex d (Flameproof)
UD20 mODEl mATRIx
