48
Test
Menu Item Display Default Range Setting
Heater output Test HeatOut Off On
High limit relay Test HiLimOut Off On
Relay 1 output Test Rly1 Out Off On
Relay 2 output Test Rly2 Out Off On
Relay 3 output Test Rly3 Out Off On
Relay 4 output Test Rly4 Out Off On
High Limit Sensor Test HL Temp (sensor reading)
Zone Cal
Menu Item Display Default Range Setting
Zone 1 actual Zone Cal Zone1Act 38°C -73°C to 760°C (-100°F to
1400°F)
Zone1 displayed Zone Cal Zone1Dis 38°C -73°C to 760°C (-100°F to
1400°F)
Zone 2 actual Zone Cal Zone2Act 260°C -73°C to 760°C (-100°F to
1400°F)
Zone2 displayed Zone Cal Zone2Dis 260°C -73°C to 760°C (-100°F to
1400°F)
Factory calibration* Zone Cal FactCal Ready Ready or Done (push- key)
*only use when no calibration instrument is available
Sensor Cal
Menu Item Display Default Range Setting
Control Sensor Cal Ctrl Sens 0F
Ctrl Sens 1000F
Ctrl Sens Done -100°F
1400°F
Done -100 to 1400°F
-100 to 1400°F
(read only)
HiLim Sensor Cal HL Sens 0F
HL Sens 1000F
HL Sens Done -100°F
1400°F
Done -100 to 1400°F
-100 to 1400°F
(read only)
Retransmit Cal RetCalLo XXXX *
RetCalHi XXXX * 0
4096 0 to 4096**
0 to 4096***
* note that the actual RetCalLo and RetCalHi values displayed are of no
importance.
** press keys until retransmission output = 1VDC
*** press keys until retransmission output = 5VDC
