29

Watlow EZ-Zone PM Controller


The process value appears in the upper display and the set point is in the lower display.

Keys and
Displays

Description

Upper Display

In the Home Page, displays the process value, otherwise displays the value of the
parameter in the lower display.

Temperature Units Indicates whether the temperature is displayed in Fahrenheit or Celsius.

Percent Units

Lights when the controller is displaying values as a percentage or when the open-loop
set point is displayed.

Lower Display

Indicates the set point or output power value during operation, or the parameter whose
value appears in the upper display.

Zone Display

Indicates the controller zone. 1 to 9 = zones 1 to 9. A=zone 10, b=zone 11, C=zone 12,
d=zone 13, E=zone 14, F=zone 15, h=zone 16.

Channel Display

Indicates the channel for any given EZ-ZONE module.

EZ keys

This key can be programmed to do various tasks, such as starting a profile.

Infinity Key

Press to back up one level or press and hold for two seconds to return to the Home
Page. From the Home Page clears alarms and errors if clearable.

Advance Key

Advances through parameter prompts

Up and Down
Keys

In the Home Page, adjusts the set point in the lower display. In other pages, changes
the upper display to a higher or lower value, or changes a parameter selection.

Output Activity

Number LEDs indicate activity of outputs. A flashing light indicates output activity

Profile Activity

Lights when a profile is running. Flashes when a profile is paused.

Communication
Activity

Flashes when another device is communicating with this controller.



Refer to the manufacturer’s instructions for additional information on displays and
navigation and to familiarize yourself with the operation of this control.
