A-51643 Rev. 6 10/06/03 13
774 306 Sunday Run Mode Auto Start Sun[Mode] 1 or 2 (Note 1) 0=Off, 1=Manual, 2=Timer, 3-10=Profile 1-8
775 307 Sunday Run Time Auto Start Sun[Time] 1 or 2 (Note 1) 00h00m to 23h59m
776 308 Monday Run Mode Auto Start Mon[Mode] 1 or 2 (Note 1) 0=Off, 1=Manual, 2=Timer, 3-10=Profile 1-8
777 309 Monday Run Time Auto Start Mon[Time] 1 or 2 (Note 1) 00h00m to 23h59m
778 30A Tuesday Run Mode Auto Start Tue[Mode] 1 or 2 (Note 1) 0=Off, 1=Manual, 2=Timer, 3-10=Profile 1-8
779 30B Tuesday Run Time Auto Start Tue[Time] 1 or 2 (Note 1) 00h00m to 23h59m
780 30C Wednesday Run Mode Auto Start Wed[Mode] 1 or 2 (Note 1) 0=Off, 1=Manual, 2=Timer, 3-10=Profile 1-8
781 30D Wednesday Run Time Auto Start Wed[Time] 1 or 2 (Note 1) 00h00m to 23h59m
782 30E Thursday Run Mode Auto Start Thu[Mode] 1 or 2 (Note 1) 0=Off, 1=Manual, 2=Timer, 3-10=Profile 1-8
783 30F Thursday Run Time Auto Start Thu[Time] 1 or 2 (Note 1) 00h00m to 23h59m
784 310 Friday Run Mode Auto Start Fri[Mode] 1 or 2 (Note 1) 0=Off, 1=Manual, 2=Timer, 3-10=Profile 1-8
785 311 Friday Run Time Auto Start Fri[Time] 1 or 2 (Note 1) 00h00m to 23h59m
786 312 Saturday Run Mode Auto Start Sat[Mode] 1 or 2 (Note 1) 0=Off, 1=Manual, 2=Timer, 3-10=Profile 1-8
787 313 Saturday Run Time Auto Start Sat[Time] 1 or 2 (Note 1) 00h00m to 23h59m
788 -- 1023 314 -- 3FF Illegal, Available to application
Relay Outputs Holding Registers
Relay Output 1
1024 400 Output 1 Type Relay 1[Relay Type] 1 or 2 (Note 1) 0=Off, 1=Alarm, 2=Cycle, 3=Event
1025 401 Relay 1 Action Relay 1[Relay Action] 1 or 2 (Note 1) 0=NDE, 1=NE, 2=NDEL, 3=NEL
1026 402 Alarm 1 Type Relay 1[Alarm Type] 1 or 2 (Note 1) 0 = High, 1 = Low, 2 = +Dev, 3 = -Dev, 4 = +/-Dev
1027 403 Alarm 1 Setpoint Relay 1[AlmHi/LoSP] 1 or 2 (Note 1) read/written as xxxx deg. F.
1028 404 Alarm 1 Deviation Setpoint Relay 1[AlmDevBand] 1 or 2 (Note 1) read/written as xxxx deg. F.
1029 405 Alarm 1 Inhibit Relay 1[AlmInhibit] 1 or 2 (Note 1) 0=Disabled, 1=Enabled
1030 406 Event 1 Type Relay 1[Event Type] 1 or 2 (Note 1) 0=Time, 1=Temp
1031 407 Event 1 Setpoint Relay 1[Event SP] 1 or 2 (Note 1) read/written as xxxx deg. F.
Relay Output 2
1032 -- 1039 408 -- 40F Output 2 Holding Registers (same as Output 1) 1 or 2 (Note 1)
Relay Output 3
1040 -- 1047 410 -- 417 Output 3 Holding Registers (same as Output 1) 1 or 2 (Note 1)
Relay Output 4
1048 -- 1055 418 -- 41F Output 4 Holding Registers (same as Output 1) 1 or 2 (Note 1)
Test Mode Holding Registers
1056 -- 1062 420 -- 426 Reserved for factory use
1063 -- 1135 427 -- 46F Illegal, Available to application
Communication Holding Registers
1136 470 Controller Address Communication[Unit Addr] 1 or 2 (Note 1) 1-247
1137 471 Communications Mode Communication[Enable] 1 or 2 (Note 1) 0=Disabled, 1=Enabled
1138 472 Baud Rate Communication[BaudRate] 1 or 2 (Note 1) 0=2400, 1=4800, 2=9600, 3=19.2K, 4=38.4K
1139 473 Parity Communication[Parity] 1 or 2 (Note 1) 0=None, 1=Odd, 2=Even
1140 474 Reserved, Available to application 0 0
Real Time Clock Holding Registers
1141 475 Week Day Clock[Day] 1 or 2 (Note 1) 1=Sunday, 2=Monday, . . . 7=Saturday
1142 476 Time Clock[hh:mm] 1 or 2 (Note 1) 00h00m to 23h59m
1143 477 Enter Clock[UP to Reset CLK] 1 or 2 (Note 1) 0 = No action, >0 = Set Clock
1144 -- 1151 478 -- 47F Illegal, Reserved for standard reg.
Calibration Holding Registers
