Despatch Protocol Plus Modbus Communications - Manual (Page 13)

Chromalox Instruments and Controls
A-51643 Rev. 6 10/06/03 7
Table 4: Protocol
TM
Plus Discrete Output Address Map
Data Address Hex Address Description Security
0
$0000 Relay Output 1
0
1
$0001 Relay Output 2
0
2
$0002 Relay Output 3
0
3 $0003 Relay Output 4 0
4 -- 7
$0004 -- $0007 Illegal, Reserved for future inputs
0
8 -- 65535
$0008 - $FFFF Undefined, available for application assignment
0
