Setting Up the Machine

5

STEP 1

1

1

Remove the packing

materials from the machine

Important

Save all packing materials and the carton in
case you have to ship your machine.

Improper Setup

DO NOT plug in the AC power cord yet.

1

Remove the packing tape from the outside of
the machine.

2

Press the front cover release button and open
the front cover.

3

Remove the four pieces of orange packing
material as shown in the illustration below.

4

Hold the green handle of the drum unit. Lift the
drum unit up and then pull it out until it stops.

5

Remove the orange packing material as shown
in the illustration below.
