Dascom 7106 User Guide - Manual (Page 33)

33
Printer Operation
Mode Settings
[Datamax ® Emulation]
Top Menu Sub Menu Default Menu Remarks
Emulation Select DM4 DMI Selects DataMax ® /Zebra ® compatibility
DM4 DMI: DataMax ® IClass
DPP DM4: DataMax ® 400 like
ZPI2 DPP: DataMax ® Prodigy Plus ®
ZPI2: Zebra ® Emulation
Emulation Auto On On Selects the detection of Datamax ® and
Detect Off Zebra ® emulation.
Full Auto
After Print AutoConfigure On On Optional auto configure
Off On .... Auto configure effective.
If a peeler unit or auto-cutter is
installed, each mode is automatically
set regardless of the “function select”
setting.
Off ... Auto configure ineffective.
When a peeler unit or auto-cutter is
installed but has not been started, it is
off and the operation is selected by
“Function select”.
Function Select Tear Off Selects the type of options installed and
Tear adjusts the "paper stop" position accordingly.
Peel On* For example, the position where the label
Cut On* stops in "Tear" mode is different to that in
"Peel On" mode.
Cutter Action* Backfeed Backfeed Cutter operating method setting
Through Backfeed: it feeds back after each cutting
operation.
Through: when the number copied = n, the
back end of sheet 1 to n-1 passes through,
and the back end of the final page that is a
single sheet is copied and fed back.
Paper Position 0.00IN Peel/Cut/Tear Off The stop position can be fine tuned using
0.00mm 0.00 to 2.00 IN this menu setting. The general stop position
0.0 to 50.8mm is selected depending on the "Function"
Peel/Cut/Tear On selected above.
-1.00 to 1.00 IN
-25.4 to 25.4mm
Mode/Repeat Key Disabled LabelSet Repeat method selection
LastOne LabelSet:
Disabled Reissues multiple labels.
LastOne:
Issues only the final page.
In count case, it issues only 1 label while
continuing.
Disabled:
Makes the repeat key invalid.
Interface RS-232C Baud 9600 115200 Sets the baud rate of the serial interface.
57600 • Interface related settings are effective
38400 after the power is turned on again.
19200
9600
4800
2400
RS-232C Parity None None Sets the communication parity of the serial
Odd interface.
Even
RS-232C Length 8 bits 8 bits Sets the character length of the serial
7 bits interface.
* Effective only when the optional unit is attached.
