Danuser 2312 AugerBucket - Manual (Page 6)

6
Specifications
• Mix, transport, and dispense concrete (up to 1” slump), sand, washed gravel (3/4” max.),
wildlife feed, asphalt, agricultural grains, etc.
• 1/2 yard capacity; 3/4 yard capacity capable with optional hopper extension
• Accurate and controlled discharge – 1/2 yard in 50 seconds
• Horizontal steel auger with orbital motor drive
• Replaceable protective rubber flighting prevents binding of coarse material.
• Universal skid-steer attachment
• Quick attach frame on either side allows right- or left-hand discharge.
• Self loading from loose piles
• 7’ hose kit with flat face couplers included.
• 2 multi-linked chutes (24” & 36” long) included.
Overall Height (A) 27"
Overall Width (B) 21-1/2"
Overall Length (C) 74-1/2"
Overall Bucket Length (D) 68-1/2"
Weight 380 lbs.
Hydraulic Requirements
12 GPM
2000 PSI
Auger Length 61-1/2"
Auger Diameter without Rubber 4"
Auger Diameter with Rubber 6-1/2"
Auger Flighting Spacing 4"
