If the Self-ignition function is selected:
CONFIGURE SELF IGNITION
Not assigned
Not assigned
Not assigned
Not assigned
Not assigned
Not assigned
Modify
1. Press the button.
2. Press to activate the function.
Left Right
CONFIGURE SELF IGNITION
Activate:
Camera automatic
Camera number
ViP address
0 0 0 0 0 0 0 0
1
3. Move over the ViP address using buttons , and change it using
buttons , entering the ViP address of the external unit for which
you wish to view the camera with the Self-ignition function.
0 0 0 0 0 0 0 1
1
Left Right
CONFIGURE SELF IGNITION
Activate:
Camera automatic
Camera number
ViP address
If the Relay activation function is selected:
1. Select the mode for which you wish to change the function using ,
and press to confirm.
SET RELAY
Configuration at rest time
Configuration during call
2. Select the fields which can be changed using , and change
the value using , or .
RELAY DURING CALL
Door 0 0 0 0 0 0 0 0
Interlocutor
Activate:
Left Right
Relay 1
Door 0 0 0 0 0 0 0 0
Interlocutore
Activate: 1 Relay
Configuring key button
1. Access the installer menu.
INSTALLER MENU
Configure buttons
2. Select the Program buttons menu by pressing , and
press to access it.
3. Press to access it.
BUTTONS PROGRAMMING MENU
Configure key button
1 2
4. Select the mode for which you wish to change the function using ,
and press to confirm.
SET RELAY
Configuration at rest time
Configuration during call
5. Select the fields which can be changed using , and change
the value using , or .
RELAY DURING CALL
Door 0 0 0 0 0 0 0 0
Interlocutor
Activate:
Left Right
Relay 1
Door 0 0 0 0 0 0 0 0
Interlocutore
Activate: 1 Relay
6. Press to exit and save the changes.
