24
Chapter 5: Installation programming
Every ViP product is identified by the factory with a unique code called the Mac address. The Mac address for the product is indicated by a label on the
packaging box and another label applied directly to the product itself.
Mac Address ViP Address * Description
00252900082B 00002001 South gate external unit
00252900086C 00002002 North gate external unit
00252900023R 00000139 Apartment 1 internal unit
00252900052A 00000127 Smith apartment internal unit
Each system device must be programmed with a different code, called the ViP address. The ViP address is an 8-digit code identifying each
extension and can be entered as desired, without following any pre-set sequence. However, we recommend using a logic diagram to keep track
of the addresses entered.
A logic diagram (optional) for entering the ViP address is provided below.
Example : Building / staircase / floor /apartment
• 01 04 11 56
• 00 02 10 22
• 01 00 12 23
• 01 03 00 09
• 00 00 00 12
ViP code
Mac Address
During the installation of various products, we recommend a document is compiled to keep track of the location of the device within the
system.
An example of how to compile such a document is provided below:
* For all products, the ViP address is programmed using ViP Manager software art. 1449, with the exception of monitors art. 6202 and art. 5900, which
can be used to set the ViP address, even locally.
Reset procedure for external unit art. 4662C
1. Cut off the power supply to the external unit art. 4662C;
2. enable programming mode by moving the relevant slider;
3. set the dip switch activation code: dip switches 1-2-3 to ON, the other dip switches to OFF;
4. restore the power supply to external unit art. 4662C;
5. the external unit will now beep twice to request the confirmation code;
6. set the dip switch confirmation code: dip switches 1-2-3 to OFF, the other dip switches to ON (i.e. the opposite of the activation code);
7. exit programming mode by moving the relevant slider;
8. external unit art. 4662C will now beep for 2-3 seconds to indicate that the configuration has been reset;
9. when the beep has ended, external unit art. 4662C will start up with its factory set configuration values.
