1 - 14 3.75G/HSPA Module USIM Card Installation
Quick Start Guide
1
3.75G/HSPA Module USIM Card Installation
If you have included an optional 3.75G/HSPA module in your purchase option, follow the instructions below to
install the USIM card (which will be provided by your service provider), and then run the Mobile Partner ap-
plication. See
“Mobile Partner” on page 7 - 23 for instructions on installing the program etc.
1. Turn off the computer, and turn it over and then remove the battery (slide the latches in the direction indicated
below and slide the battery out).
2. Insert the USIM card into the slot at the rear of the battery compartment, as illustrated below, until it clicks fully
into position, and replace the battery.
Figure 1 - 7 - Battery Removal & USIM Card Insertion

USIM Card Orientation
Note that the USIM card’s readable
side (with the gold-colored contacts)
should face upwards as illustrated.
