System Map: Bottom View 1 - 13

Quick Start Guide

1

System Map: Bottom View

Figure 1 - 6

Bottom View

1.

Battery

2.

Docking Port

3.

RAM & CPU Bay
Cover

4.

Vent/Fan Intake/
Outlet

5.

Hard Disk Bay
Cover

Note: the 3.75G/HSPA
USIM Card is located un-
der the RAM & CPU Bay
Cover.

3

4

1

5

4

4

Battery Information

Always completely dis-
charge, then fully charge, a
new battery before using it.
Completely discharge and
charge the battery at least
once every 30 days or after
about 20 partial discharges.
See

“Battery Information”

on page 3 - 12

for full in-

structions.

CPU

The CPU is not a user serviceable part.

Overheating

To prevent your computer from overheating make sure nothing blocks the Vent/Fan Intake
while the computer is in use.
