System Map: Front & Left Views 1 - 11

Quick Start Guide

1

System Map: Front & Left Views

Figure 1 - 4

Front & Left Views

1.

LED Power & Com-
munication Indica-
tors

2.

DC-In Jack

3.

External Monitor
Port

4.

RJ-45 LAN Jack

5.

e-SATA Port

6.

HDMI-Out Port

7.

Vent/Fan Intake/
Outlet

8.

2 * USB 2.0 Ports

9.

ExpressCard Slot
(see page

2 - 7

)

10. 9-in-1 Card Reader

2

5

4

1

6

3

9-in-1 Card Reader

The card reader allows you to use the most popular digital storage card formats:

MMC (MultiMedia Card) / RS MMC

SD (Secure Digital) / Mini SD / SDHC / SDXC Compatible

MS (Memory Stick) / MS Pro / MS Duo

\

7

8

9

10

8
